Great versatility with multiple sensor input capability in one unit: NPN open collector, contact and square or sine wave sensor inputs

With its industry-leading 0.87 (22 mm) height display and compact body depth of only 3.6" (92 mm), the Checkline DT-501X allows mounting in tight panels or small enclosures. Added versatility is offered with its range of standard inputs which include NPN, contact and square or sine wave signals produced from devices such as pulse generators, proximity sensors, photoelectric sensors, magnetic sensors, rotary encoders and NPN OC transistors. The Checkline DT-501X is fully scalable and possesses four selectable modes allowing it to measure various process speeds, rates and times: tachome, flowme, process time span and elapsed time mode which displays the inverse to the input signal, common in oven conveyor applications. An added teaching function auto-scales the control which simplifies the set-up by properly coordinating the display with the input of the sensors signal. Analog, contact, or SSR outputs are available for additional automation control.

These enhanced features of the DT-501X Panel Me makes them the perfect choice for speed, process rate or time applications such as machining operation timing, conveyor speed, motor output, volumetric flowrate, elapsed time of oven curing etc.

Features

Industry-leading 0.87" (22 mm) height, 6 digit, red LED display enables viewing from grea distances
Integral sensor power source saves money by eliminating need to purchase a separate power supply
Scalable programming gives user the flexibility to set up and monitor virtually any process
Selectable update time allows operator to speed up/slow down display changes to facilitate process
Test mode allows instant checking of correct operational performance of the display and keys
Great versatility with multiple sensor input capability in one unit: NPN open collector, contact and square or sine wave sensor inputs
Teaching function auto-scales the display by inputting signal from sensor; saves time programming manually
NEMA 4X (IP66) front cover protection keeps wa out, permits usage in compatible plant wash-down operations
Auto Zero function zeroes the display af the final signal initiates a preprogammed time countdown
Max. Min. automatically stored into memory; quickly retrieved via keypad
1/8 DIN size with minimal depth of only 3.6" (92 mm) allows mounting in small enclosures

Specifications

Input Range

0.0067 Hz to 100 kHz in Tachome, Flowme & Elapsed time modes; 10 ms to 3600 s in Time Span mode

Input Signal Characistics

NPN open collector input: max. frequency 100 kHz / Contact input: max. frequency 20 Hz / Square wave input: max. frequency 30 kHz Sine wave input (magnetic pickup): max. frequency 10 kHz

Display Range

Tachome/Flowme:0 999999; with 10-1to 10-5decimal point position selection
Elapsed Time:0:00:00 9:59:59 (hr., min., sec., base 60) ; or 0:00 to 999:99 (second: 1/100 sec, base 10 display)
Process Time Span:0:00:00 0:59:59 (hr., min., sec., base 60) or 0.00 999.99 sec. (second: 1/100 sec, base 10 display) with zero suppression function

Display

Red 7 segment 6 digit LED, numeral height of 0.87 (22 mm); negative (-) sign available

Accuracy

Tachome/ Flowme & Elapsed Time: 0.008 % 1 digit; Process Time Span: 0.1 % 1 digit

Display Update Time

0.2, 0.5, 1, 2, 5, 10, 15, 30, 60 sec. selectabel in Tachome, Flowme & Elapsed Time modes

Auto Zero Time

Tachome & Flowme Modes: 0.1 to 150 Seconds; Elapsed Time & Time Span Modes: 0.1 to 3600 Seconds

Optional Outputs

NPN; contact relay; analog output: (selectable) 0-1, 1-5, 0-10 VDC & 4-20 mA

Power Requirement

85 264 VAC (50/60 Hz) Optional (9 35 VDC also available)
